Horizontal 550kw Hydroelectric Turbine Generator For Micro Hydro
Power Plant
overview
A Pelton turbine or Pelton wheel is a type of turbine used
frequently in hydroelectric plants. These turbines are generally
used for sites with heads greater than 1000 meters.
When used for generating electricity, there is usually a water
reservoir located at some height above the Pelton turbine. The
water then flows through the penstock to specialized nozzles that
introduce pressurized water to the turbine. To prevent
irregularities in pressure, the penstock is fitted with a surge
tank that absorbs sudden fluctuations in water that could alter the
pressure.Unlike other types of turbines which are reaction
turbines, the Pelton turbine is known as an impulse turbine. This
simply means that instead of moving as a result of a reaction
force, water creates some impulse on the turbine to get it to move.
A hydraulic turbine converts the energy of flowing water into
mechanical energy. A hydroelectric generator converts this
mechanical energy into electricity. The operation of a generator is
based on the principles discovered by Faraday. He found that when a
magnet is moved past a conductor, it causes electricity to flow. In
a large generator, electromagnets are made by circulating direct
current through loops of wire wound around stacks of magnetic steel
laminations. These are called field poles, and are mounted on the
perimeter of the rotor. The rotor is attached to the turbine shaft,
and rotates at a fixed speed. When the rotor turns, it causes the
field poles (the electromagnets) to move past the conductors
mounted in the stator. This, in turn, causes electricity to flow
and a voltage to develop at the generator output terminals."
Specification
| Name | 550kw Hydroelectric Turbine Generator |
| Water Head | 142m |
| Runner Diameters | 0.85 m |
| Capacity | 550KW |
| Frequency | 50HZ |
| Generator Voltage | 400V |
| Layout pattern | vertical |
| Material(blades) | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless |
| Generator Insulation | F/F |
| Lifespan | 50 years |
Why choose us?
1. More than 20 years of industry experience, install commissioning
more than 150 equipment each year
2. Provide complete proposal for hydro power plant from water to
wire
3. Abundant foreign power plant project implementation experience
such as France, Japan, USA, South Africa, Sri Lanka, Iran,
Southeast Asia
4. Design and manufacture of hydro power generator with voltage
400V,6.3KV . capacity exceed 1000kw with 400V
FAQ
1.You are a trading company or a manufacture?
We are a hydro turbine generator manufacture with over 20 years of
experiences, Our factory is in the Sichuan you will take 2 hours
driving after you reach Shuangliu Airport, pay a visit to our
factory you will know more about us.
2.What Kind of water turbine should I choose?
We need to know water head, flow rate, voltage level, frequency,
on-grid or off-grid running, automation level from you to work out
the solution
3: Can you do the EPC for the hydro power plant?
Yes, We can design, producing and install the equipment, we will
dispatch technologist and workers to install the equipment.
